HANS LASER (NEW) FIBER LASER
HANS LASER (NEW) FIBER LASER
Contact us for price
Location:Little Rock, AR
orCall 1 501-897-1110
Description
HANS LASER (NEW) MODEL G17050L-IPG-Y FIBER LASER
10 KW IPG
55′ X 11.5′ SHEET (17 M X 3.5 M)
10 KW IPG FIBER RESONATOR WITH WATER CHILLER
AUTO-FOCUS CUTTING HEAD
AIR COMPRESSOR
DONALDSON DFOE6 DUST COLLECTOR SYSTEM
METALIX CNC KAD PROGRAMMING AND NESTING SOFTWARE
POWER STABILIZER
UL LISTED TRANSFORMER
696″ X AXIS TRAVEL
143.7″ Y AXIS TRAVEL
7″ Z AXIS TRAVEL
+/- 0.006 X AXIS POSITION ACCURACY
+/- 0.002 Y AXIS POSITION ACCURACY
+/- 0.003 X AXIS REPEATABILITY
+/- 0.002 Y AXIS REPEATABILITY
HANS 901 DIGITAL CONTROL – 19″ TOUCHSCREEN
STANDARD FEATURES
– BOSCH REXROTH INDRAMAT DRIVE AND SERVO SYSTEM
– STARTER CONSUMABLES AND TOOLS
– AUTO LUBRICATION SYSTEM
OPTIONS AVAILABLE – PRICE ON REQUEST
– GAS MIXER FOR ALUMINUM BURR IMPROVEMENT
SPECIFICATIONS AND CONDITION ARE CORRECT TO THE BEST OF OUR KNOWLEDGE AND ARE SUBJECT TO YOUR VERIFICATION AND CORRECTION. THE CONDITION OF THE MACHINE IS AS IT HAS BEEN REPRESENTED TO US. ALL MACHINES ARE SUBJECT TO PRIOR SALE. EVERY MACHINE, UNLESS OTHERWISE SPECIFIED, IS OFFERED SUBJECT TO OUR GUARANTEE THAT IF FOUND TO BE MECHANICALLY UNSATISFACTORY WITHIN 30 DAYS AFTER SHIPMENT, SAME MY BE RETURNED, FREIGHT PREPAID FOR FULL CREDIT OR REPAIRED AT DEALER’S OPTION. ALL MACHINES RETURNED TO US MUST BE IN AS GOOD A CONDITION AS WHEN SHIPPED.
Specifications
Model | G17050L-IPG-Y FIBER LASER |
Condition | New |
